3.5″-Speaker Rubber Surround – EPDM Rubber Edge

Short Description:

Main feature: excellent ozone resistance, excellent aging resistance, excellent chemical corrosion resistance and ultraviolet protection

The displayed product is one of our well sale products, which is made of EPDM material with 2-inch rubber edge. EPDM rubber surround is the ideal choice for outdoor speakers, gaskets and fasteners, because it has excellent anti-ultraviolet performance.
For quotation, samples or customized OEM/ODM request,
please click the button below, we are happy to reply.



Business Type: Manufacturer with OEM/ODM service

Product Detail

Product Tags

Product Detail

Product Detail

Surface Treatment:

surface treatment

Edge design

Edge design

Customizd Contetn

Material NBR SBR IIR EPDM Foaming
Size 1mm-21mm 1mm-21mm 1mm-21mm 1mm-21mm 3mm-12mm
Hardness 45°-85° 45°-85° 45°-85° 45°-85° 55°-75°
Thicken 0.15mm-10mm 0.15mm-10mm 0.15mm-10mm 0.15mm-10mm 0.15mm-10mm
Shape Round, oval, irregular, etc., accept foreign molds, and support customized molds
Color Black, gray, etc. according to customer requirements
Surface treament Smooth, frosted, undercut, etc. according to customer requirements
Edge design High-pressure strip, texture, reverse concave edge, notch, punching, etc. according to customer requirements



The quality of the rubber edge has a great impact on the frequency response of the speaker, and the hardness directly affects the frequency of the speaker. The service life of rubber ring is also very long.

EPDM rubber surround has excellent resilience and is an ideal choice for outdoor speakers, gaskets and fasteners.

EPDM is a terpolymer of ethylene, propylene and non-conjugated dienes, which began commercial production in 1963. The annual consumption of the world is 800000 tons. The main characteristic of EPDM is its superior oxidation resistance, ozone resistance and corrosion resistance. As EPDM belongs to the polyolefin (PO) family, it has excellent vulcanization properties. Among all rubbers, EPDM has the lowest specific gravity and can absorb a large amount of fillers and oil without affecting the properties. Therefore, it can produce low-cost rubber compounds. EPDM is a terpolymer of ethylene, propylene and unconjugated dienes. Dienes have a special structure, and only one of the two bonds can be copolymerized. Unsaturated double bonds are mainly used as the crossing point. The other unsaturated chain will not become the main chain of the polymer, but the side chain. The main polymer chain of EPDM is completely saturated. This property makes EPDM resistant to heat, light, oxygen, especially ozone. EPDM is non-polar in nature, resistant to polar solutions and chemicals, low water absorption and good insulation characteristics.

Our advantages

Our advantages2


Port: Shen Zhen/Guang Zhou/Ning Bo/Shang Hai

Package:Export Standard Unified Carton Packaging.

Special service: help find low freight and freight counter-offer



Q1: Can you make OEM/ODM or custom order?
Answer 1: We welcome OEM/ODM or customized product list.

Q2: What is the packaging of your products?
Answer 2: The packaging method is based on the cartons uniformly used by the company, and special packaging will be charged separately.

Q3: Can I get samples from you for testing?
Answer 3: Customers are welcome to take samples for testing. Our company supports free samples of existing models. You only need to bear the freight.

Q4: What are the terms of payment?
Answer 4: 30% T/T deposit, 70% T/T balance payment before delivery. If there is special need, it can be negotiated.

Q5: Can I visit your factory?
Answer 5: 1. In the epidemic environment, our company provides remote online factory detection service. Please contact our business. 2. Welcome to visit the company for field inspection. Please make an appointment in advance before the investigation, so as not to delay your schedule.
